Product Overview

The Ixxat CANbridge NT 200 is a configurable CAN-to-CAN bridge/router designed to connect different CAN systems. It offers two CAN channels and supports long-distance communication, with advanced message processing and multiplexing functionalities. This makes it ideal for efficient network management and system expansion.

Features and Benefits

• Seamless system integration
CANbridge NT 200 enables the simple coupling of CAN systems and supports the conversion of networks with different bit rates or frame formats. Ensures compatibility across a wide range of devices.

• Bridge operation for CAN system expansion
Bridge mode enables straightforward message exchange between CAN systems, allowing the creation of flexible network topologies such as tree or star structures.

• Cost savings through simplified wiring
Optimised network layouts reduce wiring complexity, resulting in fewer cables and lower installation and maintenance costs.

• On-device intelligence
Advanced filtering, ID translation, data mapping, and multiplexing functions streamline network traffic and improve overall efficiency.

• Customisable actions
Supports additional programming of action rules using LUA, enabling tailored responses to specific network events.

• Device and system protection
Galvanic isolation enables network segmentation, protecting devices from damage caused by voltage peaks.

• Configurable security levels
Defined access levels allow controlled configuration changes and secure firmware updates.

• Easy configuration and maintenance
A Windows-based configuration tool enables simple setup and maintenance via USB.
